Terrain Sculpt Tools Acceptance

Evidence record — not current product guidance. Use the documentation index for current behavior and architecture.

Issue: Gitea #23

Scope: native Wayland debug editor; packaged acceptance remains deferred by project-owner direction.

Live Evidence

The committed terrain showcase was selected in Forward rendering. Enabling the mountains tool kept the actor selected, removed the transform gizmo, expanded Raise/Lower/Flatten/Smooth/Noise plus radius/strength controls inside the existing horizontal viewport toolbar, and displayed the modal cancel/undo hints. A dragged Raise stroke visibly changed the generated terrain while the footprint tracked the sampled surface. Release produced exactly Undo: Raise Terrain; no transform Move history entry was created.

Escape/right-click restoration, deterministic brush math, exact vertical-ray sampling, multi-dab stroke grouping, and sculpt-time gizmo exclusion are covered by focused tests. The live pass also exposed and corrected toolbar click-through into raw mesh picking before this evidence was captured.

Source Verification

• cargo fmt --all -- --check
• cargo check -p editor --all-targets
• cargo clippy -p editor --all-targets -- -D warnings
• six focused terrain-sculpt/input-ownership tests
• git diff --check

The canonical fixture remains assets/levels/terrain_authoring_showcase.scn.ron; no QA-only scene or project setting is retained.
